FSN FS-L5502D 55-inch 4K UHD Surgical Display

  • Ultra‐high resolution (3840 x 2160 pixels).
  • High brightness LED technology.
  • Quad HD high definition picture.
  • Rapid signal detection, robust mode tables.
  • Built to last, rugged aluminum housing.
  • Calibrated to clinical color.
  • Image mirror, rotate, pan, zoom, freeze, picture-in-picture.
  • Model: FSL5502D

Description

FSN FS-L5502D 55-inch 4K UHD Surgical Display

FSN Medical Technologies has solutions for managing your operating room video signals. Their products are engineered and built for compatibility with other highly specialized surgical and diagnostic equipment used in surgical suites, operating rooms, emergency rooms, and procedural facilities. FSN FS-L5502D , 55″ 4K UHD medical display, is uniquely equipped to handle tasks in the demanding OR environment.

The FS-L5502D 55” 4K UHD medical display helps doctors focus on critically important procedure decisions, and be confident with precise instrumentation positioning by viewing the highest possible image clarity. Detailed picture quality makes it easier to see recessed surgical-site anatomy under high ambient light environments commonly found in minimally invasive applications. Flexible multi-display technology allows for extensive screen layout options using picture-in-picture, picture-by-picture, and quad screen layouts.

FSN’s FS-L5502D 55” 4K LED display features signal input options for DVI and DisplayPort, plus DC out power for smaller components. With a slim, sleek design and a flush-front glass bezel, the FS-L5502D is ideal for showing crystal clear 4K images, and can be mounted to most OR boom arm systems.

Model: FS-L5502D

Specifications

General Features
Panel  55 inch TFT LCD (LED)
Resolution  3840 x 2160 pixel
Aspect Ratio  16:9
Contrast Ratio  1400:1 typical
Pixel Pitch (mm)  0.315 x 0.315
Input Signal  2 x DVI-D (Dual link) 2 x DVI-D (Single link) 4 x SD/HD/3G-SDI (BNC) 2 x DisplayPort (Ver. 1.1 / 1.2)
Power Supply  SMPS (AC 100~240V, DC 24V, 11A)
Control Key  Power, Menu, PIP, Up, Down, Plus, Minus, Input
Unit Dimension  1279.4(W) x 750.2(H) x 83.5(D) mm 50.37(W) x 29.53(H) x 3.28(D) inch
Average Brightness  450 cd/m²
Response Time (G-to-G)  5 ms (avg.)
Viewing Angle (CR>10)  R/L 178, U/D 178
Weight  36.8 kg, 81.1 lbs.

Additional information

Manufacturer

FORESEESON CUSTOM DISPLAYS, INC.

Model

FS-L5502D
